Product Details

Sensor Suite

MIRA — Microclimate, Impact & Respiration Analytics

A compact 9 cm device placed among produce to log oxygen, carbon dioxide, ethylene, temperature, relative humidity, and movement during storage and transport studies.

MIRA Sensor Suite

Key Specifications

  • Oxygen sensing component: 0–25% by volume
  • Carbon dioxide sensing components: 0–5,000 ppm and 0–50,000 ppm
  • Ethylene sensing component: 0–100 ppm
  • Temperature sensing component: −40°C to +125°C; relative humidity component: 0–100% RH
  • Three-axis acceleration with selectable ±2g, ±4g, ±6g, ±8g, or ±16g ranges
  • Up to 7 days per charge with configured low-power operation
  • SD-card logging, USB-C charging/data transfer, Wi-Fi or nearby Bluetooth access

Features

  • Records gases, temperature, humidity, and movement together
  • Designed to travel with produce in crates, trucks, containers, or storage rooms
  • Stores condition records locally on a removable SD card
  • Supports nearby Wi-Fi or Bluetooth data transfer
  • Rechargeable over USB-C for longer studies

Technical Specifications

ParameterValue
Device SizeCompact 9 cm device
Oxygen Component Range0–25% by volume
Carbon Dioxide Component Ranges0–5,000 ppm and 0–50,000 ppm (0–5%)
Ethylene Component Range0–100 ppm (electrochemical)
Temperature Component Range−40°C to +125°C
Relative Humidity Component Range0–100% RH
MovementThree-axis acceleration; selectable ±2g, ±4g, ±6g, ±8g, or ±16g
Data LoggingRemovable SD card; each device stores its own condition record
ConnectivityWi-Fi via a suitable nearby access point or gateway; local Bluetooth transfer
Charging and DataUSB-C
Battery LifeUp to 7 days per charge with configured low-power operation; depends on settings and conditions
Measurement QualificationRanges describe sensing components; confirm assembled-system suitability and accuracy for the application
